TITAN NXUS Shoring System

Featuring standard 8x8’ and 10x8’ bays

Designed from the ground up to revolutionize your jobsite experience by improving cycle efficiency and crew safety.

NXUS is so efficient a two man crew can shore up to 5,000 square feet in a single day.




New Innovative Features:

  • NEW Supports up to 22” slabs without supplemental shores

  • NEW Better equipment stacking allows for deliveries of nearly 11,000 sqft per truckload. A drastic savings on shipping costs!

  • NEW NXUS Corner Beam - No more need for underslung beams for corners

  • NEW NXUS Guardrails & Screens - Quicker to install. Zero lumber needed.

  • Increased jobsite flexibility with 4', 6', 8', and 10' modules

  • The lightest 4' and 6' Aluminum Main Beams in the industry

  • Quick connections with TITAN XL Clips

  • Full-depth nailer pockets for extra secure plywood installs



THE BEST GRID FOR ANY CONDITION

Every jobsite is different, and every crew has their preference on how they want to get the job done. Flexibility and speed is the name of the game!

NXUS has the competition beat in aces.

Featured
NXUS 10x8' Grid

Supports slabs up to 8” thick.
10’ Main Beam and 8’ Secondary Beams

NXUS 8x8' Grid

Supports slabs up to 12” thick.
8’ Main Beam and 8’ Secondary Beams

NXUS 6x8' Grid

Supports slabs up to 16” thick.
6’ Main Beam and 8’ Secondary Beams

NXUS 6x6' Grid

Supports slabs up to 22”
6’ Main Beam and 6’ Secondary Beams




TITAN NXUS BEAMS

The new NXUS 4’ and 6’ Main Beams are the lightest in the industry. The NEW notched secondary beam design allows for quicker and easier “pivot-into-place" installation.

NXUS MAIN BEAMS

  • NXUS #4 MB - 3’7” (1.1m) - 22lb (10kg)

  • NXUS #6 MB - 5’7” (1.7m) - 32lb (14.5kg)

  • NXUS #8 MB - 7’7” (2.3m) - 50lb (23kg)

  • NXUS #10 MB - 9’6” (2.9m) - 65lb (29.5kg)

SECONDARY BEAMS

  • NXUS #4 SB - 3’7” (1.1m) - 10lb (4.5kg)

  • NXUS #6 SB - 5’7” (1.7m) - 14lb (6.4kg)

  • NXUS #8 SB - 7’7” (2.3m) - 18.5lb (8.3kg)

CONDITIONAL BEAMS

TITAN NXUS SHORES

The TITAN family of shores works seamlessly with the NXUS system, and is fully reverse compatible with all TITAN products. Our NEW NXUS Main Beams allows for greater hammer access during the stripping process.

NXUS SHORES

  • #1.75 Post Shore - 4’5”-6’7” (1.3-2m)

  • #2.5 Post Shore - 5’7”-9’0” (1.7-2.75m)

  • #3.5 Post Shore - 7’4”-12’4” (2.2-3.75m)

  • #4 Post Shore - 9’7”-14’4” (2.9-4.35m)

  • #5.5 Post Shore - 10’9”-18’10” (3.3-5.75m)

TITAN XL SHORES

  • XL 350 Post Shore - 7’4”-12’4” (2.2-3.8m)

  • XL 625 Post Shore - 15’2”-21’4” (4.6-6.5m)

  • XL Extensions - 1m or 2m Extensions

VERSATILITY

  • NEW Larger 8’ modules means less material and more room on the jobsite

  • TITAN Filler Beams eliminates wasteful wood fillers

  • NEW 4’ Main Beam works seamlessly with 6’, 8’ and 10’ modules

  • Fully reverse compatible with HV and XL shoring systems and components

  • Simplifies and speeds up installs by replacing most nut and bolt connections with XL Clips

CAPABILITY

  • NEW 10x8’ module supports up to 8” slabs without supplemental shores

  • 8x8’ module supports up to 12” slabs without supplemental shores

  • 8x6’ modulse supports up to 16” slabs without supplemental shores

  • 6x6’ module supports up to 22” slabs without supplemental shores

  • Full-depth nailer pocket for extra secure plywood

  • NEW NXUS Main Beams improve hammer access and speeds up the removal process

SAFETY

  • NEW 63” NXUS Guardrail Screen system improves edge safety

  • NEW NXUS Corner Beam replaces dangerous under-slung beams for corners

  • NEW Secondary beam restraint at the end of Main Beams prevents falling materials

  • NEW 4’ and 6’ Main Beams are the lightest beams in the industry

  • NEW Weld-less Main Beam end clip minimizes hidden fractures and simplifies repairs
